LED Display Trailer YES-T5D

Product number::YES-T5D

  • Double sides LED Display Trailer YES-T5D
    Double sides LED Display Trailer YES-T5D
  • LED Display Trailer YES-T5D
    LED Display Trailer YES-T5D
  • Double sides LED Display Trailer YES-T5D
  • LED Display Trailer YES-T5D

 This is the YEESO's multi-perspective LED trailer. Its hand forged into beautiful symmetrical shape. Its surface apply milk white color. People can view the screen from front side and back side.

◎ It is accord with mechanics principle, it has flexible and robust chassis with braking system, which is safe and reliable.
◎ We use patented technology and high refresh rates-by-point correction technology to ensure perfect clarity video.
◎ Patent hydraulic screen lifting/ rotating system. it can be towed by car along the road.
◎ We use imported hydraulic system to ensure accuracy.
◎ synchronous control system,which enable the function of live broadcast, karaoke OK and other activities.

Tech parameters of LED Trailer YES-T5
Chassis information
Brand YEESO External Dimension 4900mm×1600mm×2550mm
turning radius 6m Total weight 2500KG
Tire size 16 inch Tire numbers 2 units
max speed 60km/h

Vehicle mounted LED screen
LED screen dimension 2880mm×1600mm x double faces Pixel 8mm(P10、P6 option)
LED chip R、G、B: Epistar
module size 320mm(W)×320mm(H)
Brightness ≥6500cd
max consumption 1000W/㎡
average consumption 500W/㎡ life span 100000H
Mechanical control system
screen lifting system hydraulic lifting,360 degree rotating Lifting height 1200mm
Electric system
input voltage 380V output voltage 220V
electricity 50A average power consumption 0.5wh/㎡
Multimedia system
power amplifier 200W speakers 200W
video processor can support USB/DVD/HDMI/DVI/VGA Generator Two 5KW generator
External frame structure
surface paint white metal plate structure cold rolled board
brake hydraulic brake

optional fittings

1.LED screen resolution(P10、P8、P6)、LED screen size paint color

3.asynchronous control system

4.generator processor
