Mobile LED Billboard Trailer YES-T12

Product number::YES-T12
GET A QUOTATION & DETAILED SPECIFICATION GO BACK

  • Mobile LED Billboard Trailer YES-T12
    Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
    Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
    Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
    Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
    Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12
  • Mobile LED Billboard Trailer YES-T12

    This is the YEESO's most creative and fashionable product!It consist of Lamborghini shape chassis and Iphone shape LED screen. Its surface apply the golden yellow color or silver white color. Its a true perfect combination of art and mechanic.

◎ It is accord with mechanics principle, it has flexible and robust chassis with dual braking system, which is safe and reliable.
◎ We use patented technology and high refresh rates-by-point correction technology to ensure perfect clarity video.
◎ Patent hydraulic folding screen and seamless splicing technology, which is stable and secure.
◎ We use imported hydraulic system with scissors design to ensure accuracy.
◎ IPC + sound stage, which enable the function of live broadcast, karaoke OK and other activities.

Tech Parameter of YES-T12 Mobile LED trailer
Chassis Dimension
Brand YEESO External Dimension 6800mm×1920mm×2350mm(after folding)
Minimum turning radius ≤18000mm Total Weight 4750kg
Tire size 16 inch Tires number 4 units
Max speed 60km/h

Vehicle mounted LED Display
LED screen resolution 4800mm×2400mm pixel 8mm(P10、P6可选)
LED Chip R、G、B: Epistar
Module size 320mm(W)×320mm(H)
Brightness ≥6500cd
max power consumption 1000W/㎡
Average power consumption 500W/㎡ Life span 100000H
LED screen control system asynchronous control system

Mechanical control system
screen folding system lift up, then rotate, then fold, then lift down lifting height 2000mm
supporting legs four supporting legs,can lift up by 300mm,each support 5T

Electric system
Input voltage 380V output voltage 220V
currency 50A average Power consumption 0.5wh/㎡
Multimedia system
Power amplifier 200W Speakers 200W
Industrial computer Core CPU / 1G graphics card / 500G hard disk / DVD / 2G memory LCD monitor 15 inch KVM keyboard included
external frame structure
car paint gold or silver blue metal plate structure cold rolled steel board
brake hydraulic brake

Other options

1.LED screen resolution(P10、P8、P6)、LED screen size

2.car paint color

3.asynchronous control system

4.generator

5.video processor
